Temperature Gauge

  • Read More
    Bimetal Thermometer (Back Mount Type).png

    Bimetal Thermometer (Back Mount Type) BTT

    BTT back mount type thermometer adopts bimetallic measuring elements with wide temperature measurement range (-50 to 600℃). Stem length and outer diameter can be customized upon request, which makes it suitable for various industrial environment.
  • Read More

    Bimetal Thermometer with Electrical contact (Adjustable Angle Type) BTAC

    BTAC adjustable angle type thermometer with sliding contact SPST is used to control the facility connected to the thermometer. BTAC has wide temperature measuring range (-50 to 600℃), the stem length and outer diameter can be customized upon request, which makes it suitable for various industrial application.
  • Read More

    Bimetal Thermometer with Electrical Contact (Bottom Mount Type) BTIC

    BTIC back mount type thermometer with sliding contact SPST is used to control the facility connected to the thermometer. BTIC has wide temperature measuring range (-50 to 600℃), the stem length and outer diameter can be customized upon request, which makes it suitable for various industrial application.
  • Read More
    MS-FTXWF Series.png

    Remote Reading Explosion-proof Thermometer with Electrical Contact (Micro Switch Type) MS-FTXWF Series

    MS-FTXWF remote reading thermometer with micro switch, features high contact rating 5A and explosionproof enclosure, which is suitable for temp control in high current and hazardous environment.
  • Read More

    Remote Reading Thermometer with Electrical Contact (Micro Switch Type) MS-FT Series

    MS-FT series remote reading thermometer with micro switch, features high contact rating 5A, which is suitable for temperature control in high current environment.
  • Read More
    MS-IT Series.png

    Media-actuated Thermometer with Electrical Contact MS-IT Series

    MS-IT series remote reading thermometer with micro switch, features high contact rating 5A, which is suitable for temperature control in high current environment.
  • Read More

    Sanitary Bimetal Thermometer (Back mount type) BTT-S

    Sanitary Bimetal Thermometer (Back mount type)
    Model: BTT-S

    Features
    ■ OEM service
    ■ Comply with 3A sanitary standard
    ■ Back mount type
    ■ All stainless steel design
    ■ Liquid-filling available upon request
    ■ Customized stem outer diameter & length

    Main Specifications
    ▼Size
    2”, 2.5”, 3”, 4”,5”,6”
    ▼Installation type
    Back mount
    ▼Window
    PC / Tempered glass
    ▼Process connection
    Material: SS 304/SS 316
    Size:
    Tri-Clamp 0.75”(Ø24.89mm)
    Tri-Clamp 1”(Ø50.8mm)
    Tri-Clamp 1.5”(Ø50.8mm)
    Tri-Clamp 2”(Ø63.5mm)
    Tri-Clamp 2.5”(Ø76.2mm)
    Tri-Clamp 3”(Ø91.44mm)
    ▼Stem
    Material: SS 304/SS 316
    Outer diameter: 6.35mm
    (Others available upon request)
    Length: Min. 4” Max. 80”
    (Include ferrule length)
    <Thermowell can be customized in accordance with stem length>
    ▼Liquid-filling (Option)
    Glycerin/Silicon oil/
    Vegetable oil
    ▼Temperature range
    Min. -50°C
    Max. +600°C
    ▼Applicable fluid
    Liquid and gas that compatible with connection material
    ▼Protection level
    IP54 (standard) /
    IP65 (option)

    Other Specifications
    ▼Ring
    Stainless steel
    Crimp
    ▼Case
    SS 304/SS 316
    External adjustable screw
    (Hexagonal flathead screw)
    ▼Pointer
    Aluminum with black enamel
    ▼Dial face
    Red and black scale
    Blue and black scale
    ▼Measuring elements
    Bimetal
    Temperature sensing area:
    Last 50mm of stem
    ▼Temperature accuracy
    1.5% (standard) / 1% (option)
    ▼Operating temperature
    Stabilization: 3/4* F.S.
    Short-time: 1* F.S.

    Download
  • Read More

    Medium-Actuated Thermometer ITI

    Medium-Actuated Thermometer
    Model: ITI

    Features
    ■ OEM service
    ■ Media-actuated thermometer with fast response to ambient temperature
    ■ All stainless steel design
    ■ External adjustable screw
    ■ Full scale accuracy within 1.5%
    ■ Customized stem length
    ■ External adjustment screw
    ■ Dual temperature unit scale (℃/℉)

    Main Specifications
    ▼Type
    T type / I type / A type
    ▼Size
    3”, 4”,5”,6”
    ▼Window
    Glass
    ▼Installation type
    Bottom mount
    ▼Process connection
    Material: SS304
    Thread size: 1/4”, 3/8”,1/2”,3/4”,1”
    Thread type: BSPT, NPT, PF
    ▼Stem
    Material: SS 304/SS 316
    Outer diameter: 6.35mm
    (Option: 6mm, 8mm, 9.5mm, 12 mm)
    The length of stem without thread:
    T type:40 mmL
    (Min. 35 mmL for > 200℃)
    I type&A type:60mmL
    (Min. 40 mmL for > 200℃)
    ▼Temperature range
    Min. -50°C
    Max. +600°C
    ▼Applicable fluid
    Liquid and gas that compatible with SS304
    ▼Protection level
    IP 54

    Other Specifications
    ▼Ring
    Stainless steel
    Outside bayonet
    ▼Case
    SS304
    External adjustable screw
    (Hexagonal flathead screw)
    ▼Pointer
    Aluminum with black enamel
    ▼Dial face
    Red and black scale
    Pressure unit, scale, and color can be customized upon request
    ▼Measuring elements
    Media-expansion
    Temperature sensing area : last 2”~4”of stem
    ▼Temperature accuracy
    1.5% (Option: 1%)
    ▼Operating temperature
    Stabilization: 3/4* full scale
    Short-time: 1* full scale

    Download
  • Read More
    FTC Series.png

    Remote Reading Thermometer with Electrical Contact FTC series

    The remote reading thermometer equipped with a buzzer, a flashing indicator or a relay to remote control and monitor connected facility.
  • Read More
    小型遙測溫度計 FT-M系列 _1_.png

    Small Remote Reading Thermometer FT-M

    FT-M Small remote reading thermometer applicable to measure temperature of dry machine, food, refrigeration and air conditioning, and environmental oil-water separation equipment.
  • Read More

    Remote Reading Small Thermometer with Capillary RT50

    ■ OEM service
    ■ Compact design with affordable price
    ■ Suitable for temperature measurement that needs remote reading
    ■ Full scale accuracy: within 3%
    ■ Medium-actuated measurement ensuring the fastest reaction to ambient temperature
  • Read More

    Gas-actuated Thermometer (For Marine Type) ITI-M

    ITI-M gas actuated thermometer adopts all stainless steel material design with custom stem length, diameter and various process connection. Measuring principle adopts gas-actuated to ensure fast reaction to ambient temperature. With silicone oil filling, ITI-M thermometer has better shockproof performance compared to other thermometers.
