    2.5”Digital Micro Pressure Gauge DMPG-A2.5

    2.5”Digital Micro Pressure Gauge
    Model: DMPG-A2.5

    Features
    ■ OEM service
    ■ Specially design for micro pressure measurement
    ■ 4-digit LCD display with backlight, ensuring clear reading
    ■ Accuracy 0.5%
    ■ Auto power off design, reducing power consumption
    ■ Switchable pressure units - psi, mbar, mmWC, inWC
    ■ Rubber protection case available for better protective performance (option)

    Main Specifications
    ▼Size
    2.5”(68 mm)
    ▼Pressure connection
    Material: SS304L
    Laser welding
    Size: 1/4”
    Type: BSPT, NPT, PF
    ▼Pressure range
    Compound pressure
    Min.: -300…+300 mmWC
    Max.: -5000…+5000 mmWC
    ▼Applicable fluid
    Pure, non-corrosive gas
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    -10°C to +60°C
    ▼Ambient humidity
    85% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Temperature drift
    Standard temp.: 22℃
    max. error: ±1% F.S
    (0~50℃)
    ▼Protection level
    NEMA 4X /IP64
    ▼Optional accessory
    Rubber protective case

    Other Specifications
    ▼Ring
    Materia: ABS
    Screw fixed
    ▼Case material
    ABS
    ▼Screen display
    4-digit LCD display with
    yellow backlight
    ▼Refresh rate
    1 sec/times
    ▼Screen size
    33 (W) x 15 (H) mm
    ▼Pressure unit
    psi, mbar, mmWC, inWC
    ▼Resolution
    0.001
    ▼Measuring elements
    High-tech silicon chip
    ▼Accuracy
    0.5% (@22±3°C)
    1% (0°C to 50°C)
    ▼Compensated temperature
    0°C to 50°C
    ▼Power supply
    3V battery (CR123A, 1400mAh)
    ▼Battery life
    About 2 years
    ▼Weight
    110g (exclude protective case)

    Download
  • Read More
    AT211H _-1~0bar_.png

    Digital Precision Pressure Gauge AT211H

    AT211H digital pressure gauge with accuracy 0.02%, which is suitable to calibrate general and precision pressure gauge or blood pressure monitor. AT211H is an ideal choice to absolutely replace mechanical
    pressure gauge.
  • Read More

    Digital Pressure Gauge DPG-KS4.0

    Digital Pressure Gauge
    Model: DPG-KS4.0

    Features
    ■ OEM service
    ■ SS304 case & connection
    ■ 6-digit LCD display, high resolution
    ■ Accuracy ±0.5%F.S. / ±0.2%F.S.
    ■ Various pressure units available

    Main Specifications
    ▼Size
    4”(100mm)
    ▼Pressure connection
    Material: SS304
    1/2”PT
    1/2”NPT
    Other thread type available upon request
    ▼Pressure range
    0…1 to 1000 bar
    ▼Applicable fluid
    Liquid and gas that compatible with SS304
    ▼Ambient temperature
    -10°C to +60°C
    ▼Fluid temperature
    +60°C
    ▼Ambient humidity
    85% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Temperature error
    Standard temperature: 22℃ max. error: ±0.5% F.S (@0~50℃)
    ▼Protection level
    IP54
    ▼CE certificate
    EN61326-1:2013

    Other Specifications
    ▼Ring
    SS 304
    Inside bayonet
    ▼Case
    SS304
    ▼Screen display
    6-digit LCD display
    ▼Screen size
    65 x 37mm
    ▼Refresh rate
    5 times/sec
    ▼Pressure unit
    kg/cm2, bar, MPa, Pa, mmH2O, kPa, psi, mH2O
    ▼Resolution
    0.0001
    ▼Measuring elements
    High-tech silicon chip SS316L Diaphragm
    ▼Accuracy
    ±0.5%F.S. / ±0.2%F.S.
    ▼Operating pressure
    Overpressure: 1.5* full scale
    Burst pressure: 2* full scale
    ▼Temperature compensation
    0°C to 50°C
    ▼Power supply
    AA batteries x 2 or
    3.6V lithium battery
    ▼Battery life
    About one year (depends on the frequency of use)
    ▼Weight
    480g

    Download
  • Read More

    Digital Pressure Gauge (General Type) DPG-3.0

    Digital Pressure Gauge (General Type)
    Model: DPG-3.0

    Features
    ■ OEM service
    ■ General type digital pressure gauge
    ■ Battery/External power supply available
    ■ Protection level IP65
    ■ Laser welded connection
    ■ Protective rubber case
    ■ Accuracy 0.5%
    ■ Auto power off design
    ■ Maximum pressure value record
    ■ Rubber case provides better protection (option)
    ■ 4-20mA, PNP/NPN signal output available (option)

    Main Specifications
    ▼Size
    3”(75.5mm)
    ▼Pressure connection
    Material: SS304L
    Laser welding
    1/4”NPT (standard)
    1/4”PT (Option)
    Other thread types available upon request
    ▼Pressure range
    0…5 to 5000psi
    ▼Applicable fluid
    Liquid and gas that compatible with SS304L
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    -10°C to 60°C
    ▼Ambient humidity
    95% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Temperature error
    Standard temp.: 22℃
    max. error: ±0.5% F.S
    (0~50℃)
    ▼Protection level
    IP65
    ▼CE certificate
    EN61326-1: 2013
    ▼Test data
    Vibration test: 100 to 2000 Hz, 20g sinusoidal in 3 axes for 144 hours
    Humidity test: 250 Hours (40C and 90% to 95% R.H)

    Other Specifications
    ▼Ring
    Anodized aluminum alloy
    Screw fixed
    ▼Case
    ABS
    ▼Screen display
    4-digit LCD
    Yellow backlight
    ▼Power supply
    9V battery/
    24V external power supply
    ▼Refresh rate
    2 times/sec
    ▼Screen size
    30 x 14.5mm
    ▼Pressure unit
    Positive pressure unit:
    psi, bar, kg/cm2
    Vacuum pressure unit:
    inHg, mmHg, mbar
    ▼Resolution
    0.001
    ▼Measuring elements
    High-tech silicon chip
    SS 316L diaphragm
    ▼Protection (option)
    Protective rubber case
    ▼Accuracy
    0.25% (@22°C)
    0.5% (0~50°C)
    ▼Operating pressure
    Overpressure: 3*full scale
    Burst pressure: 5*full scale
    ▼Compensated temperature
    0°C to 50°C
    ▼Battery life
    One year (disposable battery)
    ▼Weight
    280g (exclude protective case)

    Download
  • Read More

    Digital Pressure Gauge DPG-S2.5

    DPG-S2.5 digital pressure gauge adopts piezoresistive silicon chip with high integrated circuit design. No moveable parts ensuring its long service life. High stability pressure sensor with high accuracy measurement makes DPG-S2.5 is suitable for measuring gas and liquid pressure on medical equipment or pneumatic machine.
  • Read More

    2.5”Digital Pressure Gauge DPG-2.5WP (BM)

    DPG-2.5WP(BM) features economic, easy-to-use and excellent performance, which is suitable for various instruments. It adopts latest temperature compensation technology to ensure ±1.0%F.S. accuracy within 0~5000psi pressure measurement.
  • Read More

    Digital Pressure Gauge (General Type) DPG-2.5

    DPG-2.5 is an economic cost, convenient use and high performance digital pressure gauge, suitable for various instrument. It adopts latest temperature compensation technology to ensure ±1.0%F.S. accuracy within 0~5000psi pressure measurement.
  • Read More

    Intelligent Pressure Switch DPS-2.5SPD3

    Intelligent Pressure Switch
    Model: DPS-2.5SPD3

    Features
    ■ The display reading color will automatically turn to red/green when alarm status is changed
    ■ Accuracy 0.5%F.S. (Max. 0.25%F.S.)
    ■ The pressure measuring elements adopt piezoresistive ceramic unit and SS 316
    ■ 7 Switchable pressure units
    ■ Protection level IP65
    ■ 3 types two sets alarm output available: Relay, NPN, PNP
    ■ Dual alarm function: hysteresis and window comparator mode
    ■ 4-20mA or 1-5V analog output available (option)
    ■ Digital RS-485 output available (option)

    Main Specifications
    ▼Gauge size
    Ø2.5”(63.5mm)
    ▼Screen size
    35.5 x 18mm
    ▼Pressure connection
    Material: SS316
    1/4”PT
    1/4”NPT
    Other thread spec. available upon request
    ▼Alarm output (option)
    NPN x2/PNP x2/Relay x2
    ▼Analog output (option)
    1~5V/4-20mA
    ▼RS485 (option)
    Address: “01” ~”FF” (0~255)
    Baud rate: 19200/9600/4800/2400
    Protocol: Modbus RTU
    ▼Screen display
    Bright red/green 0.4”LED
    ▼Power supply
    DC 14-30V
    ▼Applicable fluid
    Liquid and gas that compatible with SS 316
    ▼Operating temperature
    -10°C to +60°C
    ▼Media temperature
    -30 to +80°C
    ▼Storage temperature
    -30 to +80°C
    ▼Ambient humidity
    ≦95% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Protection level
    IP65
    ▼CE certificate
    EN 55022:1988/A1:2000 Class A
    EN 61000-3-2:2000
    EN 61000-3-3:1995/A1:2001
    EN 55024:1998/A1:2001

    Other Specifications
    ▼Display material
    NYLON66+PBT+15%GF (UL94V-0)
    ▼Sealing material
    < 16 bar: NBR ,
    > 16 bar: PVDF
    ▼Reading display range
    5-digit -19999~99999
    ▼Refresh rate
    0.1~9.9 secs
    ▼Memory mode
    Non-volatile EEPROM
    ▼Parameter setting
    Touch buttons
    ▼Accuracy
    0.5%F.S. (Max. 0.25%F.S.)
    ▼Pressure unit
    bar, kg/cm2, kPa, MPa, psi, mmHg, inHg
    ▼Overpressure
    < 60 bar: 2*F.S.
    > 60 bar: 1.5*F.S.
    ▼Burst pressure
    < 160 bar: 3*F.S.
    > 250 bar: 1.8*F.S.
    ▼Relay output mode
    HI/LO/GO/HL
    ▼Relay contact rating
    AC 250V-5A
    DC: 30V-7A
    ▼Transistor output
    Max.: DC 60V/100mA
    ▼Measuring elements
    Ceramic A12O3-96%
    SS316
    ▼Response time
    < 50ms (0~90%)
    ▼Output drive capability
    Voltage mode: 10mA
    Current mode: 10V
    ▼Thermal span/zero shift
    ±0.05%/10°C
    ▼Zero point long-term
    stability (@23±5°C)
    < 60 bar: ±0.1% /year
    > 60 bar: ±0.15% /year
    ▼Weight
    380g (include wire)

    Download
  • Read More

    Digital Pressure Switch DPS-1.0

    Digital Pressure Switch
    Model: DPS-1.0

    Features
    ■ OEM service
    ■ NPN/PNP alarm output available
    ■ 4-20mA signal output available (option)
    ■ Pressure measurement range 0⋯1 to 250bar
    ■ Accuracy±1%F.S.
    ■ Pipeline temperature measurement
    ■ Maximum pressure value record
    ■ Backlight on/off

    Main Specifications
    ▼Size
    1”(29.9 mm)
    ▼Pressure connection
    Material: SS 304L
    With O-ring sealed
    1/8”PT (F)
    1/8”NPT (F)
    Other thread type available upon request
    ▼Pressure range
    0…1 to 250bar
    ▼Switch alarm output
    NPN (standard)/PNP (option)
    Hysteresis mode/ Window comparator mode
    ▼Switch signal output (option)
    4-20 mA/1-10V
    ▼Applicable fluid
    Pure, non-corrosive gases
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    -10°C to 60°C
    ▼Ambient humidity
    95% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Temperature drift
    Standard temp.: 22℃
    max. error: ±0.5% F.S
    (0~50℃)
    ▼Protection level
    IP54

    Other Specifications
    ▼Ring
    ABS
    Screw fixed
    ▼Case
    ABS
    ▼Screen display
    4-digit LCD with backlight
    ▼Power supply
    DC 8-28V
    Recommended voltage: DC 24V
    ▼Refresh rate
    1 sec/times
    ▼Screen size
    19*8 mm
    ▼Pressure unit
    psi, bar, kg/cm2, MPa
    ▼Resolution
    0.001
    ▼Measuring elements
    High-tech silicon chip SS 316L diaphragm
    ▼Accuracy
    ±1%F.S. (@0~50°C)
    ▼Operating pressure
    Burst pressure: 2.5* full scale
    ▼Compensated temperature
    0°C to 50°C
    ▼Weight
    80g

    Download
  • Read More

    Digital Air Pressure Switch DPS-A1.0

    Digital Air Pressure Switch
    Model: DPS-A1.0

    Features
    ■ OEM service
    ■ NPN/PNP alarm output available
    ■ 4-20mA signal output available (option)
    ■ Specially designed for air pressure measurement and control
    ■ Accuracy ±0.5%F.S.
    ■ Pipeline temperature measurement
    ■ Maximum pressure value record
     ■ Backlight on/off

    Main Specifications
    ▼Size
    1”(29.9 mm)
    ▼Pressure connection
    Material: SS 304L
    With O-ring sealed
    1/8”PT (F)
    1/8”NPT (F)
    Other thread type available upon request
    ▼Pressure range
    Positive pressure▼
    0 to 10 bar
    Negative pressure▼
    -760…0mmHg
    Compound pressure▼
    -760mmHg to 10bar
    ▼Switch alarm output
    NPN (standard)/PNP (option)
    Hysteresis mode/ Window comparator mode
    ▼Switch signal output (option)
    4-20 mA/1-10V
    ▼Applicable fluid
    Pure, non-corrosive gases
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    -10°C to 60°C
    ▼Ambient humidity
    95% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Temperature error
    Standard temp.: 22℃
    max. error: ±0.5% F.S
    (0~50℃)
    ▼Protection level
    IP54

    Other Specifications
    ▼Ring
    ABS
    Screw fixed
    ▼Case
    ABS
    ▼Screen display
    4-digit LCD with backlight
    ▼Power supply
    DC 8-28V
    Recommended voltage: DC 24V
    ▼Refresh rate
    1 sec/times
    ▼Screen size
    19*8 mm
    ▼Pressure unit
    psi, bar, kg/cm2, MPa
    ▼Vacuum unit
    cmHg, inHg, kPa, atm
    ▼Resolution
    0.001
    ▼Measuring elements
    High-tech silicon chip SS 316L diaphragm
    ▼Accuracy
    ±1%F.S. (@0~50°C)
    ▼Operating pressure
    Burst pressure: 2.5* full scale
    ▼Compensated temperature
    0°C to 50°C
    ▼Weight
    80g

    Download
  • Read More

    Digital Pressure Switch DPS-3.0MD

    Digital Pressure Switch
    Model: DPS-3.0MD

    Features
    ■ OEM service
    ■ External power supply (Free power saving).
    ■ Standard: NPN output (PNP output available).
    ■ 4-20mA signal output available (option).
    ■ Pressure measurement range 0⋯5 to 5000psi.
    ■ Laser welded connection.
    ■ Highest accuracy±0.25%F.S.
    ■ Auto power off design.
    ■ Maximum pressure value record.
    ■ For great protection, rubber case is available to be purchased additionally (option).

    Main Specifications
    ▼Size
    3”(75.5mm)
    ▼Pressure connection
    Material: SS304L
    Laser welding
    1/4”NPT (standard)
    1/4”PT (option)
    Other thread type available upon request
    ▼Pressure range
    0…5 to 5000 psi
    ▼Switch alaron output
    NPN (standard) / PNP (option)
    ▼Analog signal output (option)
    4-20 mA
    ▼Applicable fluid
    Liquid and gas that compatible with SS304L
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    -10°C to 60°C
    ▼Ambient humidity
    95% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Temperature error
    Standard temp.: 22℃
    max. error: ±0.5% F.S (0~50℃)

    Other Specifications
    ▼Ring
    Anodized aluminum alloy
    Screw fixed
    ▼Case
    ABS
    ▼Screen display
    4-digit LCD
    Yellow backlight
    ▼Power supply
    DC 8-28V
    Recommended voltage: DC 24V
    ▼Refresh rate
    2 times/sec
    ▼Screen size
    30*14.5mm
    ▼Pressure unit
    Positive pressure:
    (1) Psi, bar, kg/cm2
    (2) Psi, MPa, kg/cm2
    <For negative pressure, the pressure unit should be inHg, mmHg, mbar>
    ▼Resolution
    0.001
    ▼Measuring elements
    High-tech silicon chip
    SS 316L diaphragm
    ▼Additional protection (option)
    Protective rubber case
    ▼Accuracy
    0.25% (@22°C)
    0.5% (0~50°C)
    ▼Operating pressure
    Overpressure: 3* full scale
    Burst pressure: 5* full scale
    ▼Compensated temperature
    0°C to 50°C
    ▼Weight
    270g (exclude protective case)

    Download
  • Read More

    Digital Air Pressure Switch DPS-A3.0MD

    Digital Air Pressure Switch
    Model: DPS-A3.0MD

    Features
    ■ OEM service
    ■ NPN/PNP alarm output available
    ■ 4-20mA signal output available (option)
    ■ Specially designed for air pressure measurement and control
    ■ Protection level IP65
    ■ Laser welded connection
    ■ Accuracy ±0.5%F.S.
    ■ Auto power off design
    ■ Maximum pressure value record
    ■ Rubber case provides better protection (option)

    Main Specifications
    ▼Size
    3”(75.5mm)
    ▼Pressure connection
    Material: SS304L
    Laser welding
    1/4”NPT (standard)
    Other thread type available upon request
    ▼Pressure range
    -760~0mmHg
    ▼Switch signal
    NPN (standard) / PNP (option)
    ▼Analog signal output (option)
    4-20 mA
    ▼Applicable fluid
    Pure, non-corrosive gases
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    -10°C to 60°C
    ▼Ambient humidity
    95% R.H.
    ▼Atmospheric pressure
    860…1060 mbar
    ▼Temperature drift
    Standard temp.: 22℃
    max. error: ±0.5% F.S (0~50℃)
    ▼Protection level
    IP65

    Other Specifications
    ▼Ring
    Anodized aluminum alloy
    Screw fixed
    ▼Case
    ABS
    ▼Screen display
    4-digit LCD
    Yellow backlight
    ▼Power supply
    DC 8-28V
    Recommended voltage: DC 24V
    ▼Refresh rate
    2 times/sec
    ▼Screen size
    30*14.5mm
    ▼Pressure unit
    inHg, mmHg, mbar
    ▼Resolution
    0.001
    ▼Measuring elements
    High-tech silicon chip
    SS 316L diaphragm
    ▼Additional protection (option)
    Protective rubber case
    ▼Accuracy
    0.25% (@22°C)
    0.5% (0~50°C)
    ▼Operating pressure
    Overpressure: 3* full scale
    Burst pressure: 5* full scale
    ▼Compensated temperature
    0°C to 50°C
    ▼Weight
    270g (exclude protective case)

    Download
