F-EPG mechanical refrigeration pressure gauge adopts special dial face with various refrigerants application. It has widely applied in a variety of refrigeration systems pressure measurement, such as air conditioning, refrigerant filling equipment.

All Stainless Steel Safe Pattern Pressure Gauge (with Blow-Out Back)
Model: SF-SUS

Feature
■ OEM service
■ Welded connection, maximum fluid temperature can up to 200℃
■ All stainless steel material
■ Install a blow-out back, specially design for industrial applications
■ Accuracy ±1%
■ Long service life

Main Specifications
▼Size
4”,6”
▼Window
Safety glass, O-ring sealed
▼Installation type
Bottom mount (A) /
Bottom mount with flange (B)／
Back mount (Eccentric thread) (ADE) /
Back mount with flange (Eccentric thread) (BDE)／
Back mount with U-Clamp (Eccentric thread) (UDE)／
Back mount with flange and U-Clamp (Eccentric thread) (UBDE)
▼Pressure connection
Material: SS316
Welded connection／O-ring sealed
Thread size: 1/4”,3/8”,1/2”
Thread type: BSPT, NPT, PF
Other thread specification are available upon request
▼Pressure range
Gauge pressure▼
0…0.6 to 1000bar
Negative pressure▼
-1…0bar
Compound pressure▼
-1…0 to 20bar
▼Applicable fluid
Liquid and gas that compatible with stainless steel
▼Liquid-filling
Glycerin／Silicone oil
▼Ambient temperature
Dry, silicone oil: -40°C to +60°C
Glycerin: +10°C to +60°C
▼Fluid temperature
Dry: +120°C
Glycerin: +100°C
Silicone oil: +200°C
▼Temperature drift
Every ±12 °C
max. error: ±0.3% F.S
▼Protection level
IP54 (Standard) / IP65 (Option)

Other Specifications
▼Ring
Stainless steel
▼Ring mount
Inside bayonet (Option: Outside bayonet)
▼Case
SS304
▼Pointer
Aluminum with black enamel
▼Dial face
Blue and black scale
Pressure unit, scale, & color can be customized
▼Measuring elements
Bourdon tube
Material: SS316
▼Protection design
Blow-out back
▼Movement
Stainless steel
▼Accuracy
±1%
▼Operating pressure
Stabilization 3/4* full scale
Fluctuation 2/3* full scale
Impulse 1* full scale

Downlaod

All Stainless Steel High Pressure Gauge
Model: HPPG-SUS

Features
■ OEM service
■ Specially design for high pressure measurement Maximum pressure measurement: 4000bar
■ Welded connection, maximum fluid temperature can up to 200℃
■ All stainless steel design
■ German Bourdon tube BK (bachmaier-klemmer) is available (optional)

Main Specifications
▼Size
4”, 6”
▼Installation type
Bottom mount (A) /
Bottom mount with flange (B) /
Back mount (eccentric thread) (ADE) /
Back mount with flange (eccentric thread) (BDE) /
Back mount with U-Clamp (Eccentric thread) (UDE) /
Back mount with flange and U-Clamp (Eccentric thread) (UBDE)
▼Window
Safety glass
O-ring sealed
▼Pressure connection
Material: SS316
Welded connection
Size: 1/4”, 3/8”, 1/2”
Type: BSPT, NPT, PF
Other thread specifications please specify before order
▼Pressure range
0…400 to 4000 bar
▼Applicable fluid
Liquid and gas that compatible with SS 304
▼Ambient temperature
Dry & Silicone oil filled:
-40°C to +60°C
Glycerin filled:
-20°C to +60°C
▼Fluid temperature
Dry: +120°C
Glycerin filled: +100°C
Silicone oil filled: +200°C
▼Temperature drift
Every ±12 °C
max. error: ±0.3% F.S
▼Protection level
IP54 (standard) / IP65 (option)

Other Specifications
▼Ring
Stainless steel
▼Ring mount
Inside bayonet
▼Case
SS 304
▼Pointer
Aluminum with black enamel
▼Dial face
Blue and black scale
Pressure unit, scale & color can be customized upon request
▼Measuring elements
Bourdon tube
Material: SS316
▼Additional protection (option)
Blow-out back
▼Movement
Stainless steel
▼Accuracy
1%
▼Operating pressure
Stabilization: 3/4* full scale
Fluctuation: 2/3* full scale
Impulse: 1* full scale

Download

HCP-EPG pressure sensor adopts heat treatment stainless steel diaphragm. The diaphragm with the expansion and contraction features, which can measure high pressure and ensure its service life and performance. High shock-resistance is ensured to prevent pressure gauge damaged by instant high pressure.

This special 4.5”black steel case pressure gauge with zero adjustment is suitable for general engineering or other application that required field pointer calibration.

MP-EPG micro pressure gauge with affordable price is suitable for micro pressure measurement in media compatible with liquid and gas.

MP Series pressure gauge is applicable to measure micro pressure of liquid and gas that compatible with copper alloy. Compared with the black steel case type, it has higher accuracy and better protection level.

Stainless Steel Case Safety Pattern Pressure Gauge
Model: SF-SC

Features
■ OEM service
■ Stainless steel case design
■ Install a blow-out back, specially design for industrial applications
■ Sealing connection with O-ring
■ Long service life

Main Specifications
▼Size
4”,6”
▼Installation type
Bottom mount (A) /
Bottom mount with flange (B) /
Back mount (eccentric thread) (ADE) /
Back mount with flange (eccentric thread) (BDE) /
Back mount with U-Clamp (Eccentric thread) (UDE) /
Back mount with flange and U-Clamp (Eccentric thread) (UBDE)
▼Window
Safety glass
Rubber O-ring sealed
▼Pressure connection
Material: copper alloy
Rubber O-ring sealed
Size: 1/4”,3/8”,1/2”
Type: BSPT, NPT, PF
Other thread specifications please specify before order
▼Pressure range
Gauge pressure▼
0…1 to 350bar
Negative pressure▼
-1…0bar
Compound▼
-1…0 to 20bar
▼Applicable fluid
Liquid and gas that compatible with copper alloy
▼Ambient temperature
Dry & Silicone oil filled
-40°C to +60°C
Glycerin filled
-20°C to +60°C
▼Fluid temperature
+60°C
▼Temperature drift
Every ±12 °C
max. error: ±0.3% F.S
▼Protection level
IP54 (standard) / IP65 (option)

Other Specifications
▼Ring
Stainless steel
▼Ring mount
Inside bayonet
▼Case
SS304
▼Pointer
Aluminum with black enamel
▼Dial face
Blue and black scale
Pressure unit, scale & color can be customized upon request
▼Measuring elements
Bourdon tube
Material: copper alloy
▼Safety design
Blow-out back
▼Movement
Copper alloy
▼Accuracy
3%
▼Operating pressure
Stabilization: 3/4* full scale
Fluctuation: 2/3* full scale
Impulse: 1* full scale

Download

ZPG black steel case pressure gauge with zero adjustment function is applicable to general engineering or environment required field pointer calibration.

TPG series precision test pressure gauge features high accuracy with affordable price, which is suitable for calibration authority or laboratory that need high accuracy pressure measurement.

TPG series precision test pressure gauge features high accuracy with affordable price, which is suitable for calibration authority or laboratory that need high accuracy pressure measurement.

TPG series precision test pressure gauge features high accuracy with affordable price, which is suitable for calibration authority or laboratory that need high accuracy pressure measurement.
