    All Stainless Steel Pressure Gauge with Electrical Contact (Micro-switch Type) MSPS

    MSPS contact adopts micro switch, it has better indicate accuracy, set point accuracy, and repeatability error than other contact pressure gauge. It is suitable for all kinds of pressure measurement, alarm system, industrial special oil production line.
  • Read More

    All Stainless Steel Differential Pressure Gauge (Double Bourdon Tubes Type) MDB

    All Stainless Steel Differential Pressure Gauge (Double Bourdon Tubes Type)
    Model: MDB

    Feature
    ■ OEM service
    ■ Dual Bourdon tubes front / rear measurement
    ■ Welded connection
    ■ All stainless steel design
    ■ Long service life
    ■ Max. Accuracy 1.6%

    Main Specifications
    ▼Size
    4”, 6”
    ▼Installation type
    Bottom mount (A)/
    Bottom mount with front flange (BF)/
    Bottom mount with back flange (BB)
    ▼Window
    PC (Standard)
    Option: Acrylic/Safety glass
    ▼Pressure connection
    Material: SS304
    Welded connection
    Dual Bourdon tubes front/rear connection
    Thread size: 1/2”
    Thread type: PT/NPT/PF
    ▼Thread hole pitch (Calculate from the center of the thread)
    32mm (Standard)
    23/26.5/35/37mm (Option)
    ▼Differential pressure range
    0…1 to 60 bar
    ▼Applicable fluid
    Liquid and gas that compatible with SS304
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    +100°C
    ▼Temperature drift
    Standard: 20°C
    Every±8°C
    max. error ±0.5% F.S
    ▼Protection level
    IP54

    Other Specifications
    ▼Ring
    Stainless steel
    ▼Ring mount
    Screw fixed
    ▼Case
    SS 304
    ▼Pointer
    Standard pointer▼
    Aluminum with black enamel
    Dial pointer▼
    ±50% indicates the positive and negative value of different pressure
    ▼Dial face
    Red and black scale
    ▼Measuring elements
    Dual bourdon tubes
    Material: SS304
    ▼Movement
    Copper alloy
    ▼Accuracy
    2.5% (Standard)/
    1.6% (Option)
    ▼Maximum static pressure
    1* full scale
    ▼Operation pressure
    Standard: 0.9* full scale
    Fluctuation: 0.8* full scale

    Download
  • Read More

    All Stainless Steel Differential Pressure Gauge (Dual Pointers & Bourdon Tubes Type) MDB-DPDB-SUS

    MDB-DPDB-SUS pressure gauge adopts dual Bourdon tubes as pressure sensor with dual pointers design. With its single or dual scales, MDB-DPDB-SUS can display readings from two different pressure sources at the same time.
  • Read More

    All Stainless Steel Differential Pressure Gauge (Diaphragm Type) MDD

    MDD has high pressure resistance and high anticorrosive performance. The diaphragm type pressure gauge is mainly use for the positive and negative pressure port of the filter. It is suitable for measuring differential pressure of liquid level, pump inlet and outlet, oil pipeline, pipeline gas and pressurize pump station.
  • Read More

    All Stainless Steel Differential Pressure Gauge (Single Diaphragm, Dual Bellows Type) MDI-SDDB

    MDI-SDDB differential pressure gauge measuring principle adopts single diaphragm and dual bellows. MDI-SDDB is suitable for same or different pressure sources measurement in non-crystallized and nonsolidified liquid, gas and steam that compatible with connection’s material.
  • Read More

    All Stainless Steel Differential Pressure Gauge (Bellow type) MDX

    MDX differential pressure gauge adopts bellow as pressure sensor, which is suitable for measuring the differential pressure of liquid, gas and steam from same or different pressure source.
  • Read More

    Explosion-proof Micro Pressure Gauge with Switch Contact (Inductive Switch Type) ECI-LP

    ECI-LP pressure gauge with inductive switch adopts diaphragm as measuring elements, which is suitable for micro pressure measurement. When pressure increase/decrease to set point, the contact will makes/breaks to control and alarm the connected facility.
  • Read More
    AMPS (WP).png

    Analog Pressure Gauge with Micro Switch (Weather-proof type) AMPS (WP)

    Analog Pressure Gauge with Micro Switch (Weather-proof type)
    Model: AMPS (WP)

    Features
    ■ OEM Service
    ■ Adjustable zero and span
    ■ Set point full scale adjustment

    Main Specifications
    ▼Dial diameter
    4”, 6”
    ▼Window
    Safety glass
    ▼Process connection
    1/2”NPT / PF male
    ▼Conduit connection
    (for bottom entry only)
    SPDT x 1: DIN 43650
    SPDT x 1 or SPDT x 2: M20 x 1.5 or 1/2”NPT female (adaptor available)
    ▼Cable gland
    (for back entry only) M16 x 1.5
    ▼Pressure range
    Min.: -1 kg/cm2
    Max.: 400 kg/cm2
    ▼Ambient Temperature
    -20℃ to +70℃
    ▼Applicable fluid
    Liquid and gas that compatible with SS 316
    ▼Temperature error
    Every ±8℃
    max error: ±0.5%
    ▼Protection level
    IP66

    Other Specifications
    ▼Connection type
    Back / Bottom (adaptor available)
    ▼Housing
    SS 304
    ▼Measuring elements
    Burdon tube
    Material: SS 316
    ▼Wetted parts
    SS 316
    ▼Contact
    Pure silver 999.9
    ▼Protection
    Blow-out back
    Diameter: 25mm
    ▼Accuracy (Gauge indication)
    ±1.0%
    ▼Micro switch form
    One setting point: SPDT x 1
    Two setting points: SPDT x 2
    ▼Operating voltage
    AC: 250 VAC max. (standard)
    DC: 28 VDC max. (standard)
    ▼Current
    AC: 5A max.
    DC: 5A max. (ohmic load)
    3A max. (inductive load)
    ▼Micro switch dead band
    ±2% - ±5%
    ▼Operating pressure
    Stabilization: 3/4* full scale
    Fluctuation: 2/3* full scale
    Impulse: 1* full scale
    Overpressure: 1.3* full scale

    Download
  • Read More
    AT-DC100 全鋼立式密度計開關.png

    All Stainless Steel Gas Density Monitor SF6-DS

    All Stainless Steel Gas Density Monitor
    Model: SF6-DS

    Features
    ■ OEM service
    ■ Strict overpressure and fatigue test
    ■ High frequency vibration - to eliminate residual stress in Bourdon tube
    ■ Specially design for destiny control
    ■ Gold plating contact - better conductivity and chemical stability

    Main Specifications
    ▼Size
    4”
    ▼Window
    Safety glass
    ▼Process connection
    Material: SS 316
    Welding / With O-ring sealed
    Size: 1/4”,3/8”,1/2”
    Type: BSPT, NPT, PF
    ▼Pressure range
    -1 to 6 …9 bar
    ▼Applicable fluid
    Liquid and gas that compatible with SS 316
    ▼Ambient temperature
    -40°C to +60°C
    ▼Fluid temperature
    +100°C
    ▼Temperature error
    Standard: 20℃
    Every ±8℃
    max. error: ±0.5% F.S
    ▼Protection level
    IP 65

    Other Specifications
    ▼Ring
    Stainless steel
    Concealed wiring
    Inside bayonet
    Adjust contact position by rotary button
    ▼Housing
    SS 304
    Leak rate: ≤1x10-5 (mbar/s)
    ▼Pointer
    Aluminum with black enamel
    ▼Dial face
    Red and black scale
    ▼Measuring elements
    Bourdon tube
    Material: SS 316
    ▼Movement
    Stainless steel
    ▼Accuracy
    1.5% (-30~ +60°C)
    2.5% (-40~ +70°C)
    ▼Operating pressure
    Stabilization: 3/4* full scale
    Fluctuation: 3/4* full scale
    Impulse: 1* full scale
    ▼Contact material
    Gold plating
    ▼Contact number
    Up to four sets
    At least one set
    ▼Electrical connection
    Terminal box
    ▼Maximum voltage
    380 VAC & 220 VDC
    ▼Maximum load
    30W or 50VA
    ▼Current interrupt
    1.0A (Max)
    ▼Initial current
    1.0A (Max)
    ▼Permanent current
    0.6A (Max)
    ▼High pressure test
    2kV, 50Hz, 1s or higher
    ▼Sealing ability
    Leak rate: ≤1x10-5 (mbar/s)
    ▼Impact resistance
    300m/s2

    Download
  • Read More

    Bimetal Thermometer with Electrical contact (Adjustable Angle Type) BTAC

    BTAC adjustable angle type thermometer with sliding contact SPST is used to control the facility connected to the thermometer. BTAC has wide temperature measuring range (-50 to 600℃), the stem length and outer diameter can be customized upon request, which makes it suitable for various industrial application.
  • Read More

    Bimetal Thermometer with Electrical Contact (Bottom Mount Type) BTIC

    BTIC back mount type thermometer with sliding contact SPST is used to control the facility connected to the thermometer. BTIC has wide temperature measuring range (-50 to 600℃), the stem length and outer diameter can be customized upon request, which makes it suitable for various industrial application.
  • Read More

    Stainless Steel Case Refrigeration Gauge (Liquid-Filling Type) F-L

    F-L mechanical refrigeration pressure gauge adopts special dial face with various refrigerants application. The liquid-filling type provides excellent shockproof performance with longer service life.
